Electronic Marking System
3M
™
EMS Ball Markers
The 3M EMS Ball Markers have a self-leveling design providing accurate, horizontal position regardless of
how the ball is placed in the ground, making the job of precisely locating underground facilities easier.
Product
3M Order Code
Programmable/
Passive
Application
Colour
Depth
Diameter
1401-XR
80611161136
Passive
Telephone
Orange
1.5 m
102 mm
1402-XR
80611161144
Passive
Power
Red
1.5 m
102 mm
1403-XR
80630000323
Passive
Water
Blue
1.5 m
102 mm
1404-XR
80630000331
Passive
Wastewater
Green
1.5 m
102 mm
1405-XR
80630000257
Passive
Gas
Yellow
1.5 m
102 mm
1407-XR
80611161151
Passive
CATV
Orange/Black
1.5 m
102 mm
1408-XR
80611168354
Passive
General Purpose/
Recyclable Water
Purple
1.5 m
102 mm
1421-XR/ID
80611142193
Programmable
Telephone
Orange
1.5 m
102 mm
1422-XR/ID
80611142201
Programmable
Power
Red
1.5 m
102 mm
1423-XR/ID
80611143225
Programmable
Water
Blue
1.5 m
102 mm
1424-XR/ID
80611143233
Programmable
Wastewater
Green
1.5 m
102 mm
1425-XR/ID
80611143241
Programmable
Gas
Yellow
1.5 m
102 mm
1427-XR/ID
80611142219
Programmable
CATV
Orange/Black
1.5 m
102 mm
1428-XR/ID
80611142227
Programmable
General Purpose/
Recyclable Water
Purple
1.5 m
102 mm
3M
™
EMS Full-Range Markers
3M EMS Full-Range Markers provide an accurate, convenient, long lasting method of marking
underground facilities. The marker has a range of up to 2.4 metres from marker to locator.
Product
3M Order Code
Programmable/
Passive
Application
Colour
Depth
Diameter x Thickness
1250
80610221071
Passive
Telephone
Orange
2.4 m
381 mm x 17 mm
1251
80610221295
Passive
Power
Red
2.4 m
381 mm x 17 mm
1252
80610221519
Passive
Water
Blue
2.4 m
381 mm x 17 mm
1253
80610221501
Passive
Wastewater
Green
2.4 m
381 mm x 17 mm
1254
80610221550
Passive
Gas
Yellow
2.4 m
381 mm x 17 mm
1248-XR/ID
80611321284
Programmable
General Purpose/
Recyclable Water
Purple
2.4 m
381 mm x 17 mm
1250-XR/ID
80611321235
Programmable
Telephone
Orange
2.4 m
381 mm x 17 mm
1251-XR/ID
80611321243
Programmable
Power
Red
2.4 m
381 mm x 17 mm
1252-XR/ID
80611321250
Programmable
Water
Blue
2.4 m
381 mm x 17 mm
1253-XR/ID
80611321268
Programmable
Wastewater
Green
2.4 m
381 mm x 17 mm
1254-XR/ID
80611321276
Programmable
Gas
Yellow
2.4 m
381 mm x 17 mm
