2
Scotch
®
Electrical, Industrial &
Special Use Tapes
PVC Electrical Tapes - Professional Use
Scotch
®
Super 33+
™
Vinyl Electrical Tape
Scotch
®
Super 33+
™
Vinyl Electrical Tape is a premium grade, 0.18 mm thick, flame retardant, all weather
vinyl insulating tape. It is designed to perform continuously between a temperature range of -18 to 105°C.
It has excellent resistance to abrasion, moisture, alkalis, acids, corrosion and varying weather conditions
(including ultraviolet exposure). The combination of elastic backing and aggressive adhesive provides moisture
tight electrical and mechanical protection with minimum bulk. Scotch
®
Super 33+
™
Vinyl Electrical Tape is an
Underwriters’ Laboratories Listed and Canadian Standards Association Certified “Insulating Tape.” Available in
custom sizes in addition to standard sizes below.
Agency Approvals:
Applications:
Primary insulation for splices up to 600 V and 105°C
Protective jacketing in indoor and outdoor environments
Product
3M Order
Code
Colour
Width
Length
Thickness
Dielectric
Strength
Breaking
Strength
Operating
Temperature
Super 33+ 19 mm x 20 m 80611207012
Black
19 mm
20 m
0.18 mm 45 kV/mm 2.6 kN/m -18 to 105°C
Super 33+ 19 mm x 33 m 80610138929
Black
19 mm
33 m
0.18 mm 45 kV/mm 2.6 kN/m -18 to 105°C
Super 33+ 25 mm x 33 m 80014001020
Black
25 mm
33 m
0.18 mm 45 kV/mm 2.6 kN/m -18 to 105°C
Scotch
®
Vinyl Colour Coding Electrical Tape 35
Scotch
®
Vinyl Electrical Tape 35 is a 0.18 mm thick PVC colour-coding, flame retardant tape. Outstanding electrical and mechanical properties
make this tape excellent for use in phase identification, colour coding of motor leads and piping systems, and for marking safety areas.
Scotch
®
Tape 35 operates over a wide range of temperatures between 0 to 105°C. This tape is available in a range of fade-resistant colours.
Agency Approvals:
Applications:
Phase identification and marking
Harnessing
Insulating splices up to 600 V
Product
3M Order
Code
Colour
Width
Length
Thickness
Dielectric
Strength
Breaking
Strength
Operating
Temperature
35 Blue
80610833925
Blue
19 mm
20 m
0.18 mm 49 kV/mm 3.0 kN/m 0 to 105°C
35 Green
80610834048
Green
19 mm
20 m
0.18 mm 49 kV/mm 3.0 kN/m 0 to 105°C
35 Red
80610833909
Red
19 mm
20 m
0.18 mm 49 kV/mm 3.0 kN/m 0 to 105°C
35 White
80610833982
White
19 mm
20 m
0.18 mm 49 kV/mm 3.0 kN/m 0 to 105°C
35 Yellow
80610833966
Yellow
19 mm
20 m
0.18 mm 49 kV/mm 3.0 kN/m 0 to 105°C
Scotch
®
Heavy Duty Vinyl Electrical Tape 22
Scotch
®
Heavy Duty Vinyl Electrical Tape 22 is one of 3M’s thickest (0.25 mm) premium vinyl electrical tapes.
It is designed for insulation applications that require greater mechanical strength and abrasion resistance.
Scotch
®
Tape 22 provides moisture-resistant electrical and mechanical protection with fewer wraps than
thinner tapes.
Agency Approvals:
Applications:
Bus bar insulation
Cable jacket repair
Product
3M Order
Code
Colour
Width
Length
Thickness
Dielectric
Strength
Breaking
Strength
Operating
Temperature
22 - 19 mm x 33 m 80012017044
Black
19 mm
33 m
0.25 mm 47.2 kV/mm 3.5 kN/m -10 to 80°C
22 - 25 mm x 33 m 80012017051
Black
25 mm
33 m
0.25 mm 47.2 kV/mm 3.5 kN/m -10 to 80°C
22 - 38 mm x 33 m 80012017069
Black
38 mm
33 m
0.25 mm 47.2 kV/mm 3.5 kN/m -10 to 80°C
22 - 50 mm x 33 m 80012017077
Black
50 mm
33 m
0.25 mm 47.2 kV/mm 3.5 kN/m -10 to 80°C
