12
Scotch
®
Electrical, Industrial &
Special Use Tapes
Product
3M Order Code Colour
Width* Length* Thickness
Breaking
Strength
Adhesion to
Steel
Static Charge Generation at 50% RH
Remove from Roll
Remove from
Stainless Steel
40PR - 6.4 mm x 66 m 80610872592
Clear with
printing
6.4 mm 66 m 0.056 mm 3.5 kN/m 17 N/100mm
5 V
5 V
40PR - 19 mm x 66 m 80610872642
Clear with
printing
19 mm 66 m 0.056 mm 3.5 kN/m 17 N/100mm
5 V
5 V
3M
™
Temflex
™
Cotton Friction Tape 1755
3M Temflex Cotton Friction Tape 1755 is a high-grade, black friction tape designed to provide mechanical
protection against abrasion and cut-through for cable, wire splices and connections insulated with rubber
electrical tape. The 0.33 mm thick tape is composed of a high quality cotton fabric, coated on both sides with
an electrical grade, solvent free, rubber adhesive. Temflex Tape 1755 has high break strength and low stretch,
making it ideal as a heavy duty binding and harnessing tape.
Applications:
Abrasion protection for splices and connections
Product
3M Order Code
Colour
Width
Length
Thickness
Breaking
Strength
Operating
Temperature
1755 - 19 mm x 18.3 m 80611604283
Black
19 mm
18.3 m
0.33 mm
8.4 kN/m
Up to 80°C
Special Use Tapes
3M
™
Antistatic Utility Tape 40PR
General use utility tape, clear polyester film backing, anti-static conductive polymer adhesive. With preprinted
static symbol. Helps prevent electrostatic discharge (ESD) damage to sensitive electronic components in
manufacturing environments.
Applications:
For use in static sensitive areas
Closing static shielding bags
*Also available from 3M converters in other standard and custom sizes.
Scotch
®
Pipe Thread Sealant Tape 48
A high temperature-stable (PTFE) thread sealant that provides a leak-proof seal.
Product
3M Order Code
Colour
Width
Length
Thickness
Operating
Temperature
48 - 12.7 mm x 33 m 80018003915
White
12.7 mm
33 m
0.076 mm
-268 to 260°C
3M
™
Armorcast Structural Material
3M Armorcast Structural Material (roll format) is packed dry in a sealed foil envelope and is a flexible
fiberglass knit fabric strip that has been saturated with a curable black urethane resin syrup that starts to
cure when water is added. Once wet, the fiber strip becomes tacky and sticks to itself, so it wraps easily
around almost any shape or size. Armorcast Structural Material is resistant to moisture, fungus, acid, alkali,
ozone, sunlight, gasoline and high temperatures. It combines long life and very little maintenance.
Applications:
Creates maintenance free mechanical protection for power cable splices
For strengthening old cable, splices and auxiliary seals
For sheath repairs as well as repairs to lead auxiliaries
Product
3M Order Code
Width
Length
4560 - 100 mm x 3 m
YP206100015
100 mm
3 m
