20
Resin Joint Kits
3M
™
Scotchcast
™
Inline Resin Power Cable Splice Kits 82-A Series
(available in NZ only)
Use the 3M Scotchcast Inline Resin Splice Kits 82-A Series to insulate and seal single conductor,
unshielded cable splices through 5 kV and multiple conductor cables through 1 kV. For use with UL listed
connectors only.
Agency Approvals:
Important:
Use cable or connector diameter for final ordering criteria
This range is only available in New Zealand
Applications:
Indoor, outdoor, underground and submerged applications
Product
3M Order Code
(NZ only)
Cable Size
Connector Diameter
(maximum)
Cable Diameter
(maximum)
Joint Configuration
Mould Body
82-A1
80610981567
Up to 30 mm²
10 mm
16 mm
Inline
Standard two-part
82-A2
80610981575
35 - 80 mm²
16 mm
25 mm
Inline
Standard two-part
82-A3
80610981583
95 - 200 mm²
25 mm
40 mm
Inline
Standard two-part
3M
™
Scotchcast Resin Cable
Joint Kits and Resins
