3M
™
Scotchcast
™
Hazardous Area Resin Cable Joint Range
Scotchcast Hazardous Area Resin Cable Joints feature 3M
™
Scotchcast
™
Insulating Resin 1402FR.
Scotchcast 1402FR resin is flame retardant, halogen free, and remains virtually unaffected by
immersion in hydrocarbons and chemical solvents. When exposed to petrol, diesel and aggressive
solvents, rapid deterioration can be experienced by standard encapsulating resins – especially those
commonly found in conventional, low cost resin jointing kits. 1402FR is an ultra-high quality, highly
modified resin that demonstrates superior performance compared to other encapsulating resin
types. 3M Scotchcast Hazardous Area resin joint kits are recommended for industrial or specialist
applications where hydrocarbons are present.
Applications:
Indoor, outdoor, underground and submerged applications
For use within Zone 1 and 2 areas
Product
3M Order Code
Cable Type
Cable Diameter
Joint
Configuration
Mould Body
Main
Branch
LVI-3/2-C*
KE235119523
Armoured
14 - 30 mm
Inline
Flame retardant two-part
LVI-3/3-C*
KE235119531
Armoured
23 - 35 mm
Inline
Flame retardant two-part
LVI-3/4
KE235119549
Armoured
28 - 47 mm
Inline
Flame retardant two-part
LVI-3/5
KE235119556
Armoured
35 - 60 mm
Inline
Flame retardant two-part
LVI-3/6
KE235119564
Armoured
45 - 70 mm
Inline
Flame retardant two-part
LVI-3/7
KE235119572
Armoured
45 - 90 mm
Inline
Flame retardant two-part
LVI-3/8
KE235120810
Armoured
45 - 100 mm
Inline
Flame retardant two-part
LVI-3/2-IC KE235119580
Instrumentation/Control,Armoured
14 - 30 mm
Inline
Flame retardant two-part
LVI-3/3-IC KE235119598
Instrumentation/Control, Armoured
23 - 35 mm
Inline
Flame retardant two-part
LVI-3/4-IC KE235119606
Instrumentation/Control,Armoured
28 - 47 mm
Inline
Flame retardant two-part
LVI-3/5-IC KE235119614
Instrumentation/Control, Armoured
35 - 60 mm
Inline
Flame retardant two-part
LVI-3/6-IC KE235119622
Instrumentation/Control,Armoured
45 - 70 mm
Inline
Flame retardant two-part
LVI-3/2-C-TM* AT019314882
Termite Protection, Armoured
14 - 30 mm
Inline
Flame retardant two-part
LVI-3/3-C-TM* AT010589193
Termite Protection, Armoured
23 - 35 mm
Inline
Flame retardant two-part
LVI-3/4-TM AT010589201
Termite Protection, Armoured
28 - 47 mm
Inline
Flame retardant two-part
LVI-3/5-TM AT010589227
Termite Protection, Armoured
35 - 60 mm
Inline
Flame retardant two-part
LVI-3/8-TM AT010589235
Termite Protection, Armoured
45 - 100 mm
Inline
Flame retardant two-part
LVI-3/2-IC-TM AE010590303 Instrumentation/Control, Termite Protection, Armoured 14 - 30 mm
Inline
Flame retardant two-part
LVI-3/3-IC-TM AE010590311 Instrumentation/Control, Termite Protection, Armoured 23 - 35 mm
Inline
Flame retardant two-part
LVI-3/4-IC-TM AE010590295 Instrumentation/Control, Termite Protection, Armoured 28 - 47 mm
Inline
Flame retardant two-part
92-NBB1-U KE235109110
Non Armoured
11 - 23 mm 11 - 23 mm Branch (Y config)
Express one-part
92-NBB2-U KE235109128
Non Armoured
16 - 33 mm 16 - 33 mm Branch (Y config)
Express one-part
*Connectors (crimp) included
