3M ANZ Electrical Catalogue 2015 Low Res - page 22

17 www.3M.com.au/electrical •www.3M.co.nz/electrical
Cable Cross Section (mm2 ) 1 Core 2 Cores 3 Cores 4 Cores
1.5 N/A LVI-2/2-C* LVI-2/2-C* LVI-2/2-C*
2.5 N/A LVI-2/2-C* LVI-2/2-C* LVI-2/2-C*
4 N/A LVI-2/2-C* LVI-2/2-C* LVI-2/2-C*
6 N/A LVI-2/2-C* LVI-2/2-C* LVI-2/2-C*
10 N/A LVI-2/3-C* LVI-2/3-C* LVI-2/3-C*
16 N/A LVI-2/3-C* LVI-2/4 LVI-2/4
25 N/A LVI-2/3-C* LVI-2/4 LVI-2/4
35 N/A LVI-2/4 LVI-2/5 LVI-2/5
50 LVI-2/3-C* LVI-2/5 LVI-2/5 LVI-2/5
70 LVI-2/3-C* LVI-2/5 LVI-2/6 LVI-2/6
95 LVI-2/4 LVI-2/6 LVI-2/6 LVI-2/7
120 LVI-2/4 LVI-2/6 LVI-2/7 LVI-2/7
150 LVI-2/4 LVI-2/6 LVI-2/7 LVI-2/7
185 LVI-2/5 LVI-2/7 LVI-2/7 LVI-2/8
Cable Cross Section (mm2) 1 Core 2 Cores 3 Cores 4 Cores
1.5 92-NBA0 92-NBA0 92-NBA0 92-NBA0
2.5 92-NBA0 92-NBA0 92-NBA0 92-NBA0
4 92-NBA0 92-NBA0 92-NBA0 92-NBA0
6 92-NBA0 92-NBA0 92-NBA0 92-NBA1
10 92-NBA0 92-NBA1 92-NBA1 92-NBA1
16 92-NBA0 92-NBA1 92-NBA1 92-NBA3
25 92-NBA0 92-NBA3 92-NBA3 92-NBA3
35 92-NBA0 92-NBA3 92-NBA3 92-NBA3
50 92-NBA0 N/A 92-NBA3 92-NBA4
70 92-NBA1 N/A 92-NBA4 92-NBA5
95 92-NBA1 N/A 92-NBA5 92-NBA5
120 92-NBA1 N/A 92-NBA5 92-NBA6
150 92-NBA3 N/A 92-NBA6 92-NBA6
185 92-NBA3 N/A 92-NBA7 92-NBA7
Resin Joint Kits - Low Voltage
Selection Table
Inline joint kits for non-armoured cable
Inline joint kits for armoured cable
*Connectors (crimp) included
Note: Final determining factor is the cable diameter
