Splicing and Insulating Tapes - Glass Cloth
Scotch
®
Glass Cloth Electrical Tapes 27
Scotch
®
Glass Cloth Electrical Tape 27 is a 0.18 mm thick woven insulating glass cloth tape with
pressure sensitive rubber thermosetting adhesive. This tape is designed to operate in 600 volt dry
applications requiring high mechanical strength and resistance to high temperatures. The glass cloth
is specially treated and prepared to provide corrosion protection.
Agency Approvals:
Applications:
Heat stable insulation for furnace and oven controls, motor leads and switches
Provides corrosion free protection
Product
3M Order Code
Colour
Width
Length
Thickness
Breaking
Strength
Operating
Temperature
27 - 12.7 mm x 20 m 80012020352
White
12.7 mm
20 m
0.18 mm
26 kN/m
Up to 150°C
27 - 19 mm x 20 m 80012020360
White
19 mm
20 m
0.18 mm
26 kN/m
Up to 150°C
27 - 25 mm x 55 m 80012020139
White
25 mm
55 m
0.18 mm
26 kN/m
Up to 150°C
Scotch
®
Glass Cloth Electrical Tape 69
Scotch
®
Glass Cloth Electrical Tape 69 is a white glass cloth tape with a high temperature
thermosetting silicone adhesive. The thermosetting adhesive provides an increased bond once
applied in areas of high ambient temperatures. Scotch
®
Tape 69 is UL recognised for continuous
use up to 200°C. It conforms to Military Specification No. MIL-I-19166C.
Applications:
Heat stable insulation for furnace and oven controls, motor leads and switches
Replaces Scotch
®
Glass Cloth Electrical Tape 27 in locations where a higher
temperature tape is needed
Product
3M Order Code
Colour
Width
Length
Thickness
Breaking
Strength
Operating
Temperature
69 - 12.7 mm x 33 m 80018002420
White
12.7 mm
33 m
0.18 mm
31.5 kN/m
Up to 200°C
69 - 19 mm x 33 m 80012040046
White
19 mm
33 m
0.18 mm
31.5 kN/m
Up to 200°C
69 - 25 mm x 33 m 80012040053
White
25 mm
33 m
0.18 mm
31.5 kN/m
Up to 200°C
