3
PVC Electrical Tapes - General Use
3M
™
PVC Electrical Tape 1710N
3M PVC Electrical Tape 1710N is a good quality general purpose PVC insulating tape. It has very good
resistance to abrasion, moisture, alkalis, acids, copper corrosion and varying weather conditions. It is flame
retardant, has a high wet dielectric strength, is conformable, and provides excellent mechanical protection
with minimum bulk. This tape is an Underwriters’ Laboratories Listed and Canadian Standards Association
Certified “Insulating Tape.”
Agency Approvals:
Applications:
Primary electrical insulation for all wire and cable joints rated up to 600 volts and 80°C
Protective jacketing for cable joints and repairs
Harnessing of wires and cables
For indoor or outdoor applications
Product
3M Order
Code
Colour
Width
Length
Thickness
Dielectric
Strength
Breaking
Strength
Operating
Temperature
1710N Black
XE000724635
Black
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Blue
XE000724668
Blue
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Green
XE000724676
Green
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Red
XE000724650
Red
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N White
XE000724643
White
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Yellow XE000724684
Yellow
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Yellow/Green XE000724692 Yellow/Green Stripe
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Rainbow NZ* XE000724700
Rainbow NZ
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
1710N Rainbow AU** XE000724718
Rainbow AU
18 mm
20 m
0.18 mm 39.4 kV/mm 2.6 kN/m 0 to 80°C
3M
™
Temflex
™
General Purpose Electrical Tape 1610 (available in AU only)
3M Temflex Electrical Tape 1610 is a good quality, economical, general purpose vinyl insulating tape. Temflex
Tape 1610 is designed for use in phase identification, colour coding of motor leads and piping systems and
for marking safety areas. It has very good resistance to abrasion, moisture, alkalis, acids and varying weather
conditions (including sunlight).
Applications:
Phase identification
Colour coding
Harnessing
Product
3M Order
Code
Colour
Width
Length
Thickness
Dielectric
Strength
Breaking
Strength
Operating
Temperature
1610 Black
AE010586764
Black
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Blue
AE010586749
Blue
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Brown
AE019172450
Brown
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Green/Yellow AE010586723 Green/Yellow Stripe
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Grey
AE019312394
Grey
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Orange
AE019312329
Orange
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Red
AE010586731
Red
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 White
AE010586756
White
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
1610 Rainbow AE010601407
Rainbow
19 mm
20 m
0.15 mm 39.4 kV/mm 2.8 kN/m 0 to 80°C
*Rainbow NZ pack includes 2 rolls each of black, white, red, blue and green
**Rainbow AU pack includes 3 rolls of black, 2 rolls each of white, red and blue, and 1 roll of yellow/green stripe
**Rainbow pack includes 3 rolls of black, 2 rolls each of white, red and blue, and 1 roll of yellow/green stripe
Note:Available in Australia only
3M
™
Scotchkote
™
Electrical Coating
provides vinyl tapes with an extra oil, moisture and
corrosion resistant layer of flexible coating for problem areas.
See page 34 for more details.
