11
Special Use Tapes
3M
™
Scotchrap
™
Corrosion Protection Tape 50
3M Scotchrap Corrosion Protection Tape 50 is a tough PVC tape with high tack adhesive that resists
corrosion of metal piping systems above and below ground. It applies over a wide temperature range
and is resistant to impact, abrasion and punctures. Coat the pipe or other metal surfaces with 3M
Scotchrap Pipe Primer before wrapping with Scotchrap Tape 50.
Applications:
Protects pipe, conduits and fittings from corrosion
3M
™
VHB
™
Tape RP45
3M
™
VHB
™
Tape RP45 is a conformable, double-sided, pressure sensitive, closed-cell acrylic foam tape
with a paper liner. Excellent permanent bonding to most surfaces used in a wide range of general industrial
bonding applications. This permanent assembly tape bonds high and medium surface energy substrates.
Provides handling convenience, cushioning, damping, and impact resistance. UV and weather resistance for
exterior and interior applications.
Applications:
Bonding a lens to a metal sign frame, washing machine touch panel bonding, commercial
vehicle roof vent attachment, commercial vehicle trim attachment, interior rail car construction.
3M
™
Double Sided Foam Tape 4466W
3M
™
Double Sided Foam Tape 4466W is a polyethylene, conformable, double coated, closed-cell foam
tape. It provides “quick stick” and conformability for a wide range of surfaces.
Applications:
Bonding, attaching and mounting. Indoor use only
Product
3M Order Code
Colour
Width
Length
Thickness
Breaking
Strength
Installation
Temperature
Range
Service
Temperature
Range
50 - 25 mm x 30 m 80008006621
Black
25 mm
30 m
0.25 mm 3.5 kN/m -12 to 65°C -48 to 80°C
50 - 50 mm x 30 m 80008006639
Black
50 mm
30 m
0.25 mm 3.5 kN/m -12 to 65°C -48 to 80°C
50 - 100 mm x 30 m 80008006647
Black
100 mm
30 m
0.25 mm 3.5 kN/m -12 to 65°C -48 to 80°C
50 - 150 mm x 30 m 80008006654
Black
150 mm
30 m
0.25 mm 3.5 kN/m -12 to 65°C -48 to 80°C
Product
3M Order Code
Colour
Width
Length
Thickness
Operating Temperature
RP45 - 12.7 mm x 5 m 70006743044
Grey
12.7 mm
5 m
1.1 mm Up to 93°C long term. Up to 121°C short term
RP45 - 19 mm x 5 m 70006743168
Grey
19 mm
5 m
1.1 mm Up to 93°C long term. Up to 121°C short term
Product
3M Order Code
Colour
Width
Length
Thickness
Operating Temperature
4466W - 12 mm x 10 m AT019314783
White
12 mm
10 m
1.6 mm
Up to 49°C long term. Up to 70°C short term
4466W - 18 mm x 10 m AT019314791
White
18 mm
10 m
1.6 mm
Up to 49°C long term. Up to 70°C short term
4466W - 24 mm x 10 m AT019314809
White
24 mm
10 m
1.6 mm
Up to 49°C long term. Up to 70°C short term
3M
™
Scotchrap
™
Pipe Primer
A quick-drying, non-sag rubber based primer that fills metal surface pits and irregularities, preparing the surface for tape
application. Compatible with the special adhesive on 3M Scotchrap Tapes, it enhances adhesion. To be used with 3M
Scotchrap Corrosion Protection Tape 50.
Applications:
Used with Scotchrap Corrosion Protection Tape 50 to resist corrosion of above and
below ground metal piping systems
Product
3M Order Code
Size
Pipe Primer
80610925739
3.8 L
