15
•
Featuring a one-part mould body with innovative sealing system requiring no cutting to size or taping, 3M
Scotchcast™ Resin Cable Joints offer unmatched speed of installation. 3M Scotchcast™ Closed Mix-Pour resin
bags are now enhanced with a new integrated resin delivery system. Designed to eliminate almost any chance
of skin contact and reduce vapour inhalation from the resin itself, this gives the user superb control over the
resin mixing and pouring process – avoiding unneccessary spills and wastage. Further, 3M Scotchcast™ high
quality resin compounds, renowned for their durability and reliability, are redeveloped to fully comply with the
latest global environmental and user safety regulations.
Inline
Branch
The 3M Scotchcast™ Closed Mix-Pour resin system allows mixing and pouring of the two-part resin without exposure to the user. Further, no tools or
mixing containers are required.
Sawing and taping the ends of the resin mould is
eliminated, regardless of cable size
Extra fast setup time, no tools required
Compressible foam seals at each
end of the mould body
Benefit
Simpler installation process and a reduced chance
of resin leakage - no need for extra taping
One-part mould body construction
with a top seal and fast fixing clips
Benefit
This innovative design significantly reduces the
chances of resin wastage, skin contact and
vapour inhalation
Fully integrated resin
delivery system
Benefit
3M
™
Scotchcast
™
Resin Cable Joint Kits
The 3M Scotchcast Resin Cable Joint range is designed to make the installation process faster, safer and more reliable than ever before. The range
includes hydrocarbon resistant products specially developed for the oil and gas industries, as well as dedicated products to suit armoured cable types
commonly found in mining and industrial environments. The range caters to a broad range of cable sizes and configurations, including inline and branch
jointing applications.
Features available in the new Scotchcast Resin Cable Joint Kit range include:
• “Express” one-part mould b dy with innova ive sealing system requiring no cutting to size or taping, allowing unmatched speed of installation
(excludes LVI-3 series, which uses a hydrocarbon resistant two- art mould body, nd the 82-A series sold in New Zealand).
• Closed Mix-Pour with integrated resin delivery system. Designed to eliminate almost any chance of skin contact, user safety is increased and
wastage from spills is minimized (excludes LVI-3 series and 82-A series).
• High quality 3M resin compounds which offer confidence through renowned reliability, and provide durability to avoid costly re-work and
system down time.
The 3M Scotchcast Closed Mix-Pour resin system allows mixing and pouring of the two-part resin without exposure to the
user. Further, no tools or mixing containers are required.
Sealed, two part resin bag
Integrated delivery system.
Included nozzle accessory
used for LVI-3 series
Internal mixing is safe
and clean
Resin is released and safely
poured in one easy step
