14
Scotch
®
Electrical, Industrial &
Special Use Tapes
Insulating and Conductive (OEM) Tapes
3M
™
Insulating and Conductive Tapes
continued
Product
Product
Description
Features
Total
Thickness
Operating
Temperature
UL Flame
retardant
Dielectric
Breakdown
Insulation
Resistance
Breaking
Strength
Electrical
Resistance
Adhesion
to Steel
Agency Approvals
Composite Film Tape
44
3M
™
Polyester Film
Electrical Tape 44
Economical, general purpose
composite film tape.This
puncture-resistant tape is tough and
conformable with excellent electrical
properties. For general purpose
insulation, anchoring, and banding in
motors and transformers
0.14 mm 130°C
5500 V >1 x 10
6
MΩ 7 kN/m
71 N/100 mm
ü ü
44D-A
3M
™
Reinforced Polyester
Film Electrical Tape 44D-A
A version of 44 Tape with twice
the backing thickness for greater
dielectric strength
0.30 mm 130°C
6000 V >1 x 10
6
MΩ 7 kN/m
38 N/100 mm
ü
Polyimide Film Electrical Tape
92
3M
™
Polyimide Film
Electrical Tape 92
Silicone adhesive and 0.025 mm
film. High temperature, puncture
resistant, printable, flame retardant.
Stable in coils,harnesses and
capacitors that are subjected to high
temperatures
0.08 mm 180°C
Yes
7500 V >1 x 10
6
MΩ 5.3 kN/m 28 N/100 mm
ü ü
PTFE Film Electrical Tape
60
3M
™
PTFE Film Electrical
Tape 60
Translucent, 0.05 mm PTFE film tape
with silicone adhesive. For use on
high temperature coils, capacitors
and wire harnesses. UL510 flame
retardant
0.10 mm 180°C
Yes
9500 V >1 x 10
6
MΩ 3.5 kN/m 32 N/100 mm
ü
61
3M
™
PTFE Film Electrical
Tape 61
Translucent, thicker (0.127 mm)
PTFE film tape with silicone adhesive.
For use on high temperature coils,
capacitors and wire harnesses where
high dielectric and breaking strength
are required. UL510 flame retardant
0.18 mm 180°C
Yes
15000 V >1 x 10
6
MΩ 7.9 kN/m 38 N/100 mm
ü
63
3M
™
PTFE Film Electrical
Tape 63
Translucent, 0.05 mm PTFE
film tape with solvent resistant
acrylic adhesive. For use on coils,
capacitors and wire harnesses. For
use where chemical properties are
more important than temperature
resistance
0.09 mm 155°C
Yes
9500 V >1 x 10
6
MΩ 3.5 kN/m 38 N/100 mm
ü
EMI Shielding Tapes
1170
3M
™
Aluminium Foil Tape
with Conductive Adhesive
1170
Conductive acrylic adhesive,
0.05 mm aluminium foil
0.08 mm
Yes
3.5 kN/m 0.01 Ω 38 N/100 mm
ü
1181
3M
™
Copper Foil Tape with
Conductive Adhesive 1181
Conductive acrylic adhesive,
0.04 mm copper foil
0.07 mm
Yes
4.4 kN/m 0.005 Ω 38 N/100 mm
ü
1182
3M
™
Copper Foil Tape with
Conductive Adhesive on
both sides 1182
Conductive acrylic adhesive on both
sides, 0.04 mm copper foil
0.09 mm
Yes
4.4 kN/m 0.01 Ω 38 N/100 mm
ü
1194
3M
™
Copper Foil Tape with
Nonconductive Adhesive
1194
Nonconductive adhesive,
0.07 mm copper foil
0.08 mm
Yes
4.4 kN/m n/a
51 N/100 mm
ü
1245
3M
™
Embossed Copper
Foil Tape 1245
Conductive acrylic adhesive,
embossed 0.04 mm copper foil
0.10 mm
Yes
4.4 kN/m 0.001 Ω 38 N/100 mm
ü
