3M
™
Cold Shrink Low Voltage Insulators and Kits
3M Cold Shrink Insulators offer a safe, easy to install method of insulating, sealing and protecting connectors, cable, hoses, fittings and conduit. They
are well suited for in-field applications because they require no special tools or heat to install.
The unique 3M cold shrink delivery system ensures consistent installation and long term reliability. With 3M cold shrink insulators and accessories you
get a water resistant seal without heat, torches or adhesive; simply unwind the core to install. It’s that simple.
Why move to 3M Cold Shrink Technology?
• No flame required
• Less chance of damaging cable material
• No cooling time needed before energising
• Constant radial pressure for optimised environmental performance
• Easier to use in enclosed areas
• No special site permits needed
• Fast, straightforward installation
Kit Number
3M Part Number
Sealing Application Sizes for DIN or Type N Coax Cable Connectors
CXS-1
80611207673
6.4 mm (1/4”) – 22 mm (7/8”) Cable to 6.4 mm (1/4”) – 22 mm Cable (7/8”)
CXS-2
80611207681
6.4 mm (1/4”) – 41 mm (1 5/8”) Cable to 32 mm (1 1/4”) – 41 mm Cable (1 5/8”)
32 mm (1 1/4”) – 41 mm (1 5/8”) Cable to Antenna or Surge Arrestor
CXS-3
80611207699
6.4 mm (1/4”) – 57 mm (2 1/4”) Cable to 32 mm (1 1/4”) – 57 mm Cable (2 1/4”)
32 mm (1 1/4”) – 57mm (2 1/4”) Cable to Antenna or Surge Arrestor
CXS-4
80611207707
6.4 mm (1/4”) – 22 mm (7/8”) Cable to Antenna or Surge Arrestor
3M
™
Cold Shrink Wireless Weatherproofing Kit CXS Series
3M
™
Cold Shrink Sealing Kits CXS Series use a cold shrink EPDM rubber tube, in
conjunction with a closed cell foam strip, to seal connections and terminations on
coaxial cables with Type N or 7/16 DIN connectors. 3M Cold Shrink tubes form
a reliable water-resistant seal as well as providing excellent protection in tough
environments, including resistance to UV, acids, alkalis, fungus, ozone, abrasion and
vibration. Due to no adhesive needed to create the seal, the cold shrink tubes can be
easily removed as required for system maintenance, inspection and repair.
