3M
™
Cold Shrink Low Voltage
Insulators and Joint Kits
26
Cold Shrink End Caps
Product
3M Order Code
Colour
Cable Diameter
EC-1
XA003895001
Black
12 - 21 mm
EC-2
XA003895019
Black
16 - 30 mm
EC-3
XA003895027
Black
26 - 49 mm
EC-4
XA003895035
Black
46 - 84 mm
3M
™
Cold Shrink End Caps EC-Series
3M Cold Shrink End Caps EC-Series are close-ended, tubular rubber sleeves that are factory expanded
and loaded onto a removable core. When positioned over the end of a cable or other cylindrical object,
the core is removed to provide a reliable environmental seal. Four different end caps are available to
accommodate a wide range of sizes. They are easily installed and can be removed cleanly.
Applications:
Environmentally seal and mechanically protect exposed cable ends using no tools,
mastics or tapes
Protect cables and pipes from exposure to moisture, contamination, corrosion,
ozone, ultra-violet radiation and other environmental hazards
Cable Diameter (mm)
EC-1
EC-2
EC-3
EC-4
46
- 84
26
- 49
16
- 30
12 - 21
0
10
20
30
40
50
60
70
80
90 100
