25
•
Product
3M Order Code
Cable Diameter
CSCAK/1
TE100048780
12 - 18 mm
CSCAK/2
TE100048798
18 - 25 mm
CSCAK/3
TE100048806
25 - 42 mm
CSCAK/4
TE100048814
42 - 55 mm
CSCAK/5
TE100048822
56 - 81 mm
3M
™
Cold Shrink Cable Abandonment Kits CSCAK
3M Cold Shrink Cable Abandonment Kits are a complete solution to abandon low voltage polymeric
cables either temporarily or permanently. Environmental sealing and mechanical protection is provided
using 3M Cold Shrink technology, eliminating the need for heat and special tools, making a quick, simple
and reliable installation.
Kit Contents:
• Cold shrink end cap
• Armour/earth connection components
• Cold shrink tube
• Full installation Instructions
• Self amalgamating insulating tape
Applications:
Single and multi core low voltage polymeric power cables up to and including
1.9/3.3 kV (with or without lead sheath and/or armour)
Cold Shrink Joints Kits and Cable Abandonment Kits
3M
™
Low Voltage Inline Joint Kits 5732-5735 Series
These kits are suitable for indoor and outdoor installations, including direct burial, aerial and submersible
applications. For use with three core armoured cable up to 1000 V. Connectors are not included,
pre-insulated crimp connectors preferred.
Product
3M Order Code
Cable Size
Cable Diameter
5732
80610981740
35 - 50 mm²
24 - 61 mm
5733
80610981757
70 - 120 mm²
29 - 84 mm
5734
80610981765
120 - 240 mm²
39 - 102 mm
5735
80610981773
240 - 400 mm²
39 - 102 mm
Note:
If increased structural integrity is required, the joint can be overwrapped with two-half lapped layers of 3M
™
Armorcast Structural Material
(purchased separately). For 3 metre long rolls use the following number of rolls per kit: 5732 (2 rolls), 5733 & 5734 (3 rolls) and 5735 (5 rolls).
See page 12 for ordering details.
