3M ANZ Electrical Catalogue 2015 Low Res - page 35

3M
™ Heat Shrink Tubing
30
Cable Repair Wrap Sleeve
Product 3M Order Code Cable Diameter
(maximum - minimum) Length Expanded Inner
Diameter
Recovered Inner
Diameter
Minimum Recovered
Wall Thickness
HDCW 35/10-250 DE272920799 35 - 10 mm 250 mm 50 mm 8 mm 2.0 mm
HDCW 35/10-500 DE272920781 35 - 10 mm 500 mm 50 mm 8 mm 2.0 mm
HDCW 35/10-750 DE272920773 35 - 10 mm 750 mm 50 mm 8 mm 2.0 mm
HDCW 35/10-1000 DE272920765 35 - 10 mm 1000 mm 50 mm 8 mm 2.0 mm
HDCW 55/15-250 DE272909834 55 - 15 mm 250 mm 75 mm 13 mm 2.0 mm
HDCW 55/15-500 DE272909842 55 - 15 mm 500 mm 75 mm 13 mm 2.0 mm
HDCW 55/15-750 DE272909859 55 - 15 mm 750 mm 75 mm 13 mm 2.0 mm
HDCW 55/15-1000 DE272909867 55 - 15 mm 1000 mm 75 mm 13 mm 2.0 mm
HDCW 80/25-250 DE272909883 80 - 25 mm 250 mm 100 mm 23 mm 2.0 mm
HDCW 80/25-500 DE272909891 80 - 25 mm 500 mm 100 mm 23 mm 2.0 mm
HDCW 80/25-750 DE272909909 80 - 25 mm 750 mm 100 mm 23 mm 2.0 mm
HDCW 80/25-1000 DE272909917 80 - 25 mm 1000 mm 100 mm 23 mm 2.0 mm
HDCW 110/30-500 DE272909941 110 - 30 mm 500 mm 132 mm 25 mm 2.0 mm
HDCW 110/30-1000 DE272909966 110 - 30 mm 1000 mm 132 mm 25 mm 2.0 mm
HDCW 140/40-250 DE272909982 140 - 40 mm 250 mm 145 mm 32 mm 1.8 mm
HDCW 140/40-500 DE272909990 140 - 40 mm 500 mm 145 mm 32 mm 1.8 mm
HDCW 140/40-1000 DE272910014 140 - 40 mm 1000 mm 145 mm 32 mm 1.8 mm
3M™ Heat Shrink Wraparound Cable Repair Wrap Sleeve HDCW
3M Wraparound Heat Shrink Cable Repair Sleeve HDCW is designed to repair damaged cable sheaths. It is
also suitable for use with cable joints and as additional corrosion protection on undamaged cables. Quick
and easy to apply, it provides maximum protection against mechanical stress, even in the most aggressive
environments. The inner wall of the sleeve is coated with hot melt adhesive to achieve a safe and watertight
bond with the cable and give a perfect seal when heat is applied, while a corrosion proof metal clip is used to
fully close the sleeve.
Applications: Quickly and safely repair damaged cable sheaths
Additional corrosion protection on joints or undamaged cables
